• Length = 40" - Width = 71" - Height (Closed) = 41" - Height (Open) = 62"
• Max Bale Length and Diameter - 53" - Max Bale Weight = 2,646 lbs. - Splitting Power (@ 180 bar) = 10T/100kN
• Hydraulic Connection = Double-Acting Service - Oil Pressure (Max./Min.) = 210 bar/150 bar - Oil Amount (Max./Min.) = 50L/20L
• Robust construction throughout. One double-acting hydraulic service controls both the Bale Cutter and Film Catcher.
• Uniquely designed blade ensures a closer cut to tines. Uniquely shaped film catcher designed to penetrate even frozen bales.
• Heavy cylindes fitted too unit to produce ample force to cut through even frozen bales.

Bale Cutter w Film Catcher - Weight = 882 lbs. (without bracket) - The patented Bale Cutter & Film Catcher from Cashels has been designed to increase the productivity of handling and feeding round baled silage to livestock when mounted on tractors and farm loaders. Mature silage bales vary in shape and density depending on their geographic location and climate conditions. Therefore, the unique shape of our Bale Cutter & Film Catcher ensures that the unit performs its design function of transporting, cutting in half and catching the film and net every time, regardless of the bale shape or density.

BALE CUTTER-FILM CATCHER OPERATIONS MANUAL

BALE CUTTER & FILM CATCHER BROCHURE
